SHCTR-JPR25UP
This pump replaces 1" NPT General Multi-Purpose Fluid Pump #JPR-25UP
Port Size:1" NPT
Port Type: Pipe
Body: Bronze
Impeller p/n: 7400-01 SHCTR-K-112
Shaft Material / Diameter: Stainless Steel / 17mm
Shaft Seal: Mechanical Seal
Flow (1800rpm): 106 Liter/Min
Size (L x W x H): 158mm x 103mm x 112mm
Weight (Approx): 7.0 lbs (3.18 kgs)
Service Kit (*Sold Separately): JSK0001
Product Features:
Strong Bronze Body
Long Life Mechanical Seal
High Performance and Long Life Flexible Impeller
Designed with Easy Replacement of Spare Parts
O-Ring Seals at Endcover (Impeller Cover) Instead of a Gasket
Applications:
Marine & Sewage Treatment
Industrial (ie. Cleaning Solutions, Bottling Systems)
Agricultural / Farming Public Utilities and Municipalities
SHCTR-JPR25UP |
|
---|---|
BRAND
|
JMP
|
Replaces
|
JPR-25UP
|
KEY Drive
|
Serration
|
Blade number
|
6
|
Sierra number
|
|
OEM part number
|
JPR-25UP
|
Shctr number
|
K-112
|
Shctr Water Pump Repari Kit
|
|
