SHCTR-JPR25UP

This pump replaces 1" NPT General Multi-Purpose Fluid Pump #JPR-25UP
Port Size:1" NPT
Port Type: Pipe
Body: Bronze
Impeller p/n: 7400-01 SHCTR-K-112
Shaft Material / Diameter:  Stainless Steel / 17mm
Shaft Seal: Mechanical Seal
Flow (1800rpm): 106 Liter/Min
Size (L x W x H): 158mm x 103mm x 112mm
Weight (Approx): 7.0 lbs (3.18 kgs)
Service Kit (*Sold Separately): JSK0001
Product Features:
Strong Bronze Body
Long Life Mechanical Seal
High Performance and Long Life Flexible Impeller
Designed with Easy Replacement of Spare Parts
O-Ring Seals at Endcover (Impeller Cover) Instead of a Gasket
Applications:
Marine & Sewage Treatment
Industrial (ie. Cleaning Solutions, Bottling Systems)
Agricultural / Farming Public Utilities and Municipalities

SHCTR-JPR25UP

BRAND


JMP


Replaces


JPR-25UP


KEY Drive


Serration


Blade number


6


Sierra number



OEM part number


JPR-25UP


Shctr number


K-112


Shctr Water Pump Repari Kit
